Shure sm7b mikrofonas

• For Professional Voice-Over Applications
• Dynamic, Cardioid Pickup Pattern
• Bass Roll-Off and Midrange Controls
• Detachable Windscreen

Specifikacija

Type

Dynamic (moving coil)

Frequency Response

50 to 20,000 Hz

Polar Pattern

Cardioid

Output Impedance

150 Ω

Sensitivity

(@ 1 kHz, open circuit voltage)

-59 dBV/Pa[1] (1.12 mV)

Hum Pickup

(typical, at 60 Hz, equivalent SPL/mOe)

11 dB

Polarity

Positive pressure on diaphragm produces positive voltage on pin 2 with respect to pin 3

Net Weight

0.764 kg (1.69 lbs)

Housing

Dark gray enamel aluminum and steel case with dark gray foam windscreen.

[1] 1 Pa=94 dB SPL
